Model: SI-099N MINIBEAM 50

Smaller---very compact in size and weight
Better---very high in output

The MINIBEAM 50 features a 7500K 50W LED with high intensity and efficiency. It produces very high light output, through a specific 2° optic system. The PAN/TILT integrates in fast and quiet movement. It offers a full complement of professional characteristics, including a static gobo wheel, color wheel, 8-facet prism, linear electronic focus, 0-100% linear LED dimmer, variable speed shutter/strobe.

The fixture is applicable for small-medium scale live concerts, DJ Shows, schools, clubs, weddings, etc.


  • Light Source
  • Source: 50W White LED engine
  • Color Temperature: 7500K
  • Flicker free operation for broadcast TV and FILM
  • Life Span: 50000H
  • The life span may vary depending on several following factors but not limited to:
  • Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming)

  • Optics
  • A set of high resolution and precise optics
  • 2°Projection angle
  • 2.5M-30M Linear electric focus

  • Movement
  • PAN movement: 360°/540°/630°optional (8/16 bit)
  • PAN movement: 90°/180°/270°optional (8/16 bit)
  • Fast, quiet, smooth and precise 2-Phase motors
  • Smooth, fast and precise resolution for PAN/TILT movement with low noise operation
  • Scan position memory, auto reposition after unexpected movement

  • Color System
  • 1 Color wheel with 14 dichroic colors plus open
  • Variable direction rainbow effect with speed adjustable

  • Gobo System
  • 1 Static gobo wheel with 17 gobos plus open with dithering effect

  • Prism System
  • 8-Facet prism with variable speed and direction

  • Strobe Effect
  • 25T/sec high speed LED shutter/strobe effect with variable speed
  • Preset variable/random strobe and dimming pulse effect
  • Dimming System
  • 0-100% Smooth linear LED dimming

  • Control System
  • 10/12 DMX channels USITT DMX-512
  • DMX512, master-slave, Sound activated or auto operation
  • DMX recorder and edit function integrated
  • Shielded input signal protection for stable signal without interference
  • 3-Pin XLR DMX connectors IN/OUT
  • Preset Program
  • Auto programs

  • Display System
  • LED display
  • 4 Control buttons
  • Display OFF in 60 seconds
  • DMX signal monitoring indicator

  • Cooling System
  • Advanced cooling system integrated with aluminum
  • Efficient low noise self adjusting fan cooling system
  • Over temperature protection management (output decreased when over heat)

  • Power Supply
  • Electronic supply with active PFC
  • AC100-240V 50/60Hz
  • PowerCON IN/ OUT with power switch and fuse
  • 75W Power consumption

  • Housing
  • High intension moulded fire proof ABS PC
  • Skeleton made of aluminum and steel metal plates
  • Two side handles on base
  • Exterior finish: Black (white optional)

  • Installation
  • 2*1/4 turn fastening Omega Clamps
  • 1*Safety attachment point
  • Operating Condition
  • Operating positions: all (device on floor or fixed to a support)
  • -25℃ to 45℃ ambient temperature
  • IP20 protection rating

  • Compliance
  • CE
  • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  • 2014/30/EU - Electromagnetic Compatibility (EMC)
  • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)

  • Weight
  • N.W.: 7.18kg
  • G.W.: 8.93kg

  • Dimensions
  • Product Dimensions:152(D)*270(W)*364(H)mm
  • Packing Dimensions: 240(D)*350(W)*450(H)mm


Input Voltage:AC90-260V 50/60Hz
LED Quantities:1*50W white LED
Control Signal:DMX512, master-slave and sound activated or auto operation
Control Channel: 9/11 DMX channels USITT DMX-512
Power Consumption: 55W
Dimensions:149(D)*270(W)*364(H)mm
Packing Dimensions:245(D)*350(W)*450(H)mm
Net Weight:6.20kg
Gross Weight:8.03kg

SIZE_117



EN SI-124 GOBO_1

Details

  • a.jpg
  • b_11
  • c_10
  • d_10
  • e_6
  • f_6

Effect Pictures

  • a.jpg
  • b_12
  • c_11
  • d_11
2_1

Power Cable

STANDARD
code:
QTY: 1PCS

4_1

Signal Cable

STANDARD
code:
QTY: 1PCS



4_1

Hanging Kit

STANDARD
code:
QTY: 1PCS





3_1

Safety Cable

STANDARD
code:
QTY: 1PCS





2_1

Road Case

OPTIONAL
code:
Available for 2-in-1, 4-in-1, 6-in-1 versions

2_1

Clamps

OPTIONAL
code:
QTY: 1PCS
