HEXA 6

Model: SI-285 HEXA 6

The new HEXA 6 is a special effect moving head light of an imperial lighting fixture with tremendous visual effect which is an viriation from our TRIANGLE lights. It features 6*30W 1500K+5500K LED modules, 216*0.3W 3-IN-1 LEDs (RGB) that delivers different color options by color mixing and 216*0.3W 3200K LEDs surrounding the main module as auxiliary light. All the LEDs are controllable individually by 6 sections. It also features a highly reflective mirror on the back side featuring 99% reflectance without color shift. The mirror can redictect the beams of light with high intensity. The unit offers 360°continuous PAN/TILT movement with variable speeds. This provides much more flexible control capability to the users to birght more vivid effects for performance.

The HEXA 6 supports DMX, RDM (Remote Device Management), Art-Net protocol. The fixture’s exterior housing is beautifully balanced design with supremely harmonious interior structure for remarkable control. The sculpted body of the HEXA 6 achieves more than just a striking look. It provides friendly PAN/TILT locks for safety during transportation.

The fixture is tuned with proper LED refresh rate for flicker free operation for TV and FILM. It’s a perfect option for large scale live concerts, TV productions, road shows, theatre, clubs, etc.

Light Source
Source:
6*30W LED modules, 1500K+5500K
216*0.3W 3-IN-1 SMD LEDs
216*0.3W 3200K LEDs
6 LED modules controllable individually
LED driving frequency adjustable
Flicker free operation for broadcast TV and FILM
Life Span: 50000H
The life span may vary depending on several following factors but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, etc.

Optics
A set of high temperature resistant squamous reflector optic system
60°Beam angle for each module
High reflextive mirror on the back side

Movement
PAN movement: 360°continuous (8/16 bit)
PAN movement: 360°continuous (8/16 bit)
Fast, quiet, smooth and precise 3-Phase motors
Smooth, fast (1.7s) and precise resolution for PAN/TILT movement with low noise operation
Scan position memory, auto reposition after unexpected movement
PAN/TILT reversible
