DIVER 550B SI-327


Today more and more moving heads are being exposed to wet, humid and extreme conditions. With numerous multi-environmental application requirements, Color Imagination recently launched an IP65 rated moving head beam which integrates BEAM and WASH in one fixture, featuring 2°beam angle by a large size 265mm front lens. The OSRAM SIRIUS HRI 550W pro lamp delivers high lumen through a high definition optic lens that brings incredibly ultra brightness, large size and sharp beam effect with even and clear spot image.As structure is perfectly designed with ultimate heat sink system, the DIVER 550B will keep itself in excellent performance in all functions even though in raining, dirty, sandy or water environment. There will be no accumulation of dust or external impact on inside components like optics, gobos, color filters or the light source. And there will be no smoke fluid or humidity gathering inside.
The DIVER 550B offers a full complement of professional characteristics, including CMY+CTO system, static gobo wheel, color wheel, 16-facet prism with zoom, 8+16-facet prism with zoom, frost filter, motorized linear focus, variable speed shutter/strobe; and linear mechanical dimmer, etc. The fixture supports DMX, RDM (Remote Device Management).The DIVER 550B’s applications are unlimited. It could be placed at any outdoor environment such as fountain shows, themepark,architectural shows, live concerts, and so on.

Technical specifications

  • Light Source

    Source: OSRAM SIRIUS HRI 550W lamp
    Color Temperature: 7700K (+/-300K)
    CRI≧80 (+/-5)
    Flicker free operation for broadcast
    TV and FILM
    Life Span: 1500H
    The life span may vary depending on
    several following factors but not limited to:
    Environmental Conditions, Power/Voltage,
    Usage Patterns (On-Off Cycling), Control,



    A set of high resolution and precise optics
    265mm Large size front glass lens
    2°Beam angle
    Smooth electric focus
    Fine control for focus



    PAN movement: 540°(8/16 bit)
    PAN movement: 270°(8/16 bit)
    Fast, quiet, smooth
    and precise 3-Phase otors
    Magnet encoding wheel
    integrated with motor
    Smooth, fast and precise resolution for
    PAN/TILT movement
    with low noise operation
    Scan position memory, auto reposition
    after unexpected movement
    PAN/TILT reversible


    Color System

    Full CMY color mixing system with linear
    CTO color correction
    Fine control for CMY+CTO
    1 Color wheel with 14 dichroic colors plus
    Variable direction rainbow effect with
    speed adjustable
    Fine control for color wheel


    Gobo System

    1 Static gobo wheel with 19 gobos plus
    open (gobo reducers included)
    Fine control for gobo wheel


    Prism System

    16-Facet prism with variable speed and
    8+16-Facet linear prism with variable
    speed and direction
    Prism morphing effect
    Prism zooming effect
    Prism wheel fine control


    Strobe Effect

    20T/sec high speed shutter/strobe effect
    with variable speed
    Preset variable/random strobe effect with
    variable speed


    Dimming System

    0-100% Smooth linear mechanichal
    Fine control for dimming


    Wash System

    Linear frost filter (Hybrid effect for wash)
    Fine control for frost filter
    Even and soft coverage


  • Control System

    21/32 DMX channels USITT DMX-512
    DMX512, master-slave or auto operation
    DMX recorder and edit function integrated
    RDM available (Remote Device Management)
    Art-NET (Optional)
    Wireless Solution’s wireless receiver
    system built-in (Optional)
    Shielded input signal protection for stable
    signal without interference
    IP rated RJ45 etherCON IN/OUT (Optional
    with Art-Net)
    IP rated DMX cables with 3-Pin XLR
    connectors IN/OUT


    Software Update

    Software up-datable
    through DMX connectors
    Muilt units up-datable in daisy chain


    Display System

    2.4" TFT LCD display
    5 Control buttons
    180°Reversible for LCD display
    Display auto OFF


    Cooling System

    Advanced cooling system integrated
    aluminum and copper with liquid
    Noise free featured
    Constant temperature readout and
    management function
    Over temperature protection management


    Power Supply

    Electronic ballast: OSRAM PT SIRIUS
    Electronic supply with active PFC
    AC100-240V 50/60Hz
    IP rated power cable IN/OUT
    825W Power consumption



    Die-cast aluminum housing
    with moulded fire proof ABS PC
    Skeleton made of
    aluminum and steel metal plates
    Two side handles on base
    Exterior finish: Black
    Friendly PAN/TILT locks
    for better fixture protection



    2*1/4 turn fastening Omega Clamps
    (Adaptable vertically and horizontally)
    1*Safety attachment point


    Operating Condition

    Operating positions:
    all (device on floor or fixed to a support)
    -25℃ to 45℃ ambient temperature
    IP20 protection rating



    2014/35/EU - Safety of electrical
    equipment supplied at low voltage (LVD)
    2014/30/EU -
    Electromagnetic Compatibility (EMC)
    2011/65/EU - Restriction of the use of
    certain hazardous substances (RoHS)



    N.W.: 31kg
    G.W.: 37kg



    Product Dimensions:
    Packing Dimensions:
